Product Specifications : Truck mounted crane

Truck mounted crane SQ5SK2Q / SQ5SK3Q



Model

SQ5SK2Q/SQ5SK3Q

Unit

Max Lifting Capacity

5000

kg

Max Lifting Moment

12.5

T.M

Recommend Powe

18

kw

Max Oil Flow of Hydraulic System

32

L/min

Max Pressure of Hydraulic System

18

MPa

Oil Tank Capacit

90

L

Rotation Angle

All Rotation

Crane Weight

2074/2170

kg

Installation Space

900

mm

Choice of Chassis

HOWO Chassis;CA1140PK 2L 3EA80 £» DFL1140B £» EQ1126KJ1 £» HFC1132KR1K3 £» LZ1120LAPT £» EQ1141NBJ2 £» EQ5201GFJ6 £» EQ5201GFJ6 £» NXG1160D3ZAL1X


SQ2SK1Q Lifting capability diagram

Working radius(m)

2.5

3.62

6.05

8.5

Lifting capacity(kg)

5000

2800

1500

1100


SQ2SK2Q Lifting capability diagram

Working radius(m)

2.5

3.62

6.05

8.5

11

Lifting capacity(kg)

5000

2800

1500

1100

400
