Product Specifications : Hydraulic crawler crane

Hydraulic crawler crane QUY120

¡÷ Unique function of free fall, saves oil consumption and boosts work efficiency;

¡÷ Optional equipped with self-load/unload function. Optional equipped with luffing jib condition

¡÷ Main components of power system and hydraulic system are imported from USA, Ge rmany, etc. .

¡÷ In accordance with Europe CE and North-America certification

¡÷ The easily damaged and consumable structural parts are self-made, .and special structure design by us makes maintenance more convenient.

¡÷ Most part of whole crane adopts no-dust baked lacquer automatic assemble line painting .

Product Parameters

QUY120 Hydraulic Crawler Crane Technical Parameters

Item

Unit

Data

Item

Unit

Data

Max. load capacity

t

120

Boom Hoisting Speed

m/min

¡ù54

Boom Length

m

16 ¡« 73

Boom Lowering Speed

m/min

54

Length of Main Boom + Fly Jib

m

61 + 25

Lifting Torque

tm

600

Main Boom Length for Luffing Jib

m

34 ¡« 49

Slewing Speed

r/min

0 ¡« 1.96

Luffing Jib Length

m

16 ¡« 46

Traveling Speed

Km/h

1.3/0.9

Length of Main Boom + Luffing Jib

m

46 + 46

Grade ability

£¥

30

Luffing Jib Derricking Mode



Upper Mast

Engine Output

QSL9 KW/r/min

209/2000

Light duty boom combination

m

47+34.5=81.5

Main Hoisting Line Parts



12

Boom Derricking Angle

o

30 ¡« 80 45 ¡« 88

Ground Pressure

Mpa

0.08

Hook Hoisting Speed

m/min

High 114/57 Low 82/41

Machine Weight

t

111

Hook Lowering Speed

m/min

High 114/57 Low 82/41

Counter Weight

t

42

Note: Speed varies with different load
