Product Specifications : Hydraulic crawler crane

Hydraulic crawler crane QUY150C

¡÷ Equipped with self-assembly/disassembly function

¡÷ Main components of power system and hydraulic system are imported from USA and Japan.

¡÷ Hydraulic oil cooling system adopts single warm-control, saves energy

¡÷ Unique function of free fall, saves oil consumption and boosts work efficiency; with optional luffing jib

¡÷ The easily damaged and consumable structural parts are self-made, .and special structure design by us, makes maintenance more convenient.

¡÷ Most part of whole crane adopts no-dust baked lacquer automatic assemble line painting .



Product Parameters

QUY 150C Technical Parameters

Descriptions

Unit

Data

Engine



QSL-9, Cummins

Engine output

KW/r/min

209KW /2100rpm

Lifting torque

t.m

900

Max. lifting capacity

t

150

Boom length

m

15.2-81.2

Length for fixed jib

m

13-31

Lifting capacity of jib

t

25

Hoisting

m/min

117 -142

Boom derrick

m/min

42

Max. slewing speed

r/min

0-2.3

Travel

Km/h

1.25/0.65

Gradeability

%

30

Ground pressure

Mpa

0.092/ 0.096

Weight of the crane

t

152-165

Overall dimensions£¨Length X Width X Height£©

mm

9750¡Á3380¡Á3580

Note£º*Speed may vary with the load.
